Product number |
Dimensions |
Path Length |
Path Width |
Volume |
||
ES quartz glass |
IR quartz glass |
Optical glass |
||||
190nm-2500nm |
250nm-3500nm |
340nm-2500nm |
(mm) |
(mm) |
(mm) |
(ml) |
| Q-23 | I-23 | G-23 | 45×12.5×7.5 | 5 | 4 | 0.7 |
| Q-24 | I-24 | G-24 | 45×12.5×12.5 | 10 | 4 | 1.4 |
| Q-25 | I-25 | G-25 | 45×12.5×22.5 | 20 | 4 | 2.8 |
| Q-26 | I-26 | G-26 | 45×12.5×32.5 | 30 | 4 | 4.2 |
| Q-27 | I-27 | G-27 | 45×12.5×42.5 | 40 | 4 | 5.6 |
| Q-28 | I-28 | G-28 | 45×12.5×52.5 | 50 | 4 | 7 |
| Q-29 | I-29 | G-29 | 45×12.5×102.5 | 100 | 4 | 14 |
| Q-43 | I-43 | G-43 | 45×12.5×7.5 | 5 | 2 | 0.35 |
| Q-44 | I-44 | G-44 | 45×12.5×12.5 | 10 | 2 | 0.7 |
| Q-45 | I-45 | G-45 | 45×12.5×22.5 | 20 | 2 | 1.4 |
| Q-46 | I-46 | G-46 | 45×12.5×32.5 | 30 | 2 | 2.1 |
| Q-47 | I-47 | G-47 | 45×12.5×42.5 | 40 | 2 | 2.8 |
| Q-48 | I-48 | G-48 | 45×12.5×52.5 | 50 | 2 | 3.5 |
| Q-49 | I-49 | G-49 | 45×12.5×102.5 | 100 | 2 | 7 |
| Q-133 | I-133 | G-133 | 45×12.5×7.5 | 5 | 3 | 0.5 |
| Q-134 | I-134 | G-134 | 45×12.5×12.5 | 10 | 3 | 1 |
| Q-135 | I-135 | G-135 | 45×12.5×22.5 | 20 | 3 | 2.1 |
| Q-136 | I-136 | G-136 | 45×12.5×32.5 | 30 | 3 | 3.15 |
| Q-137 | I-137 | G-137 | 45×12.5×42.5 | 40 | 3 | 4.2 |
| Q-138 | I-138 | G-138 | 45×12.5×52.5 | 50 | 3 | 5.25 |
| Q-139 | I-139 | G-139 | 45×12.5×102.5 | 100 | 3 | 10.5 |
| Q-143 | I-143 | G-143 | 45×12.5×7.5 | 5 | 5 | 0.85 |
| Q-144 | I-144 | G-144 | 45×12.5×12.5 | 10 | 5 | 1.75 |
| Q-145 | I-145 | G-145 | 45×12.5×22.5 | 20 | 5 | 3.5 |
| Q-146 | I-146 | G-146 | 45×12.5×32.5 | 30 | 5 | 5.25 |
| Q-147 | I-147 | G-147 | 45×12.5×42.5 | 40 | 5 | 7 |
| Q-148 | I-148 | G-148 | 45×12.5×52.5 | 50 | 5 | 8.75 |
| Q-149 | I-149 | G-149 | 45×12.5×102.5 | 100 | 5 | 17.5 |
| Q-424 | I-424 | G-424 | 25×12.5×12.5 | 10 | 1 | 0.15 |
| Q-434 | I-434 | G-434 | 25×12.5×12.5 | 10 | 2 | 0.3 |
| Q-444 | I-444 | G-444 | 25×12.5×12.5 | 10 | 3 | 0.45 |
| Q-454 | I-454 | G-454 | 25×12.5×12.5 | 10 | 4 | 0.6 |
| Q-634 | I-634 | G-634 | 20×12.75×12.75 | 10 | 2 | 0.05 |
| Q-644 | I-644 | G-644 | 20×12.75×12.75 | 10 | 4 | 0.1 |
| JK-micro | JK-Q23, JK-Q24, JK-Q25, JK-Q26, JK-Q27, JK-Q28, JK-Q29, JK-Q43, JK-Q44, JK-Q45, JK-Q46, JK-Q47, JK-Q48, JK-Q49, JK-Q133, JK-Q134, JK-Q135, JK-Q136, JK-Q137, JK-Q138, JK-Q139, JK-143, JK-Q144, JK-Q145, JK-Q146, JK-Q147, JK-Q148, JK-Q149, JK-Q424, JK-Q434, JK-Q444, JK-Q454, JK-Q634, JK-Q644 |
|---|
